Solutions · Wire, Cable & Extrusion
Continuous wire drawing, cable manufacturing, and extrusion lines.
A continuous strand moving fast through a process that never stops, where a diameter or speed deviation now becomes scrap much later. This is close to identical to HSCAM’s proven steel-wire deployment.
Adjacent processHSCAM’s steel-mill deployment is itself a continuous hot-wire process, directly adjacent to wire and cable manufacturing.
The problem, in this industry
Problems HSCAM has already solved in a closely adjacent process
Each of these is a real, demonstrated HSCAM capability — shown here at the pattern level, with a link to where it was actually proven.
A continuous process, watched around the clock
The process never stops, so there is no good moment to point a camera at it — every cut, cycle or pass has to be caught, not just the ones you happen to be watching for.
STREAMER cameras stream continuously over standard USB 3.0. In-camera compression of about 5:1 reduces one camera’s ~1.44 GB/s to ~300 MB/s, which allows direct recording to a suitably specified SSD.
See it demonstratedSize, speed, acceleration — measured, not estimated
Knowing a workpiece moved "too fast" or "out of tolerance" isn’t enough — the measurement has to be tied to the exact video frame it happened on, or it can’t be trusted.
Image and measurement data are captured on the same camera clock, so a workpiece’s position, speed or acceleration lines up with the video frame it belongs to.
See it demonstratedA fault found hours or days later, traced back to the moment it happened
The defect surfaces downstream — in quality control, in the next process step, or in a customer complaint — long after the event itself. By then the moment is gone unless it was recorded.
In the steel-mill installation a week or more of recordings was kept and reviewable in slow motion (triggered recording, 20–200 TB of storage), so a defect found later could be traced back to the cut that caused it.
See it demonstratedThe evidence behind this page
- Closest reference
- Steel wire at up to 140 m/s
- Recorded at
- 3,000 fps, 1,024 × 160 px
- Synchronization
- Video + ADC on one clock
The adjacent steel-wire installation. No wire-drawing, cable or extrusion deployment yet.
See the full applicationWhat helps us scope a request in this industry
- Strand speed and diameter
- Which deviation you need to catch: diameter, speed, surface or breaks
- Whether line speed or tension signals should be recorded with the video
- How long a recording has to stay available after a fault
Recognize this problem in your own process? HSCAM is looking for pilot projects in industries like this one.
Talk to an engineer about wire, cable & extrusion
Tell us your process, your speed, and what you need to see or measure.
Helpful, but not required
- What your process does and what goes wrong, or what you cannot see today
- Speed or cycle time, if you know it
- Measurement or trigger signals that exist on the machine
- Environment: temperature, lighting, mounting space
