Solutions · Printing & Converting
Web-fed printing, laminating, and converting lines.
A continuous web moving through print, coat or laminate stations, where registration errors or tears are found downstream and need to be traced back to a roll position.
Capability fitShows how HSCAM’s demonstrated capabilities — continuous monitoring, latent-fault diagnosis, and workpiece characterization — apply to printing and converting lines.
The problem, in this industry
Demonstrated capabilities relevant to this industry
Each of these is a real, demonstrated HSCAM capability — shown here at the pattern level, with a link to where it was actually proven.
A continuous process, watched around the clock
The process never stops, so there is no good moment to point a camera at it — every cut, cycle or pass has to be caught, not just the ones you happen to be watching for.
STREAMER cameras stream continuously over standard USB 3.0. In-camera compression of about 5:1 reduces one camera’s ~1.44 GB/s to ~300 MB/s, which allows direct recording to a suitably specified SSD.
See it demonstratedA fault found hours or days later, traced back to the moment it happened
The defect surfaces downstream — in quality control, in the next process step, or in a customer complaint — long after the event itself. By then the moment is gone unless it was recorded.
In the steel-mill installation a week or more of recordings was kept and reviewable in slow motion (triggered recording, 20–200 TB of storage), so a defect found later could be traced back to the cut that caused it.
See it demonstratedSize, speed, acceleration — measured, not estimated
Knowing a workpiece moved "too fast" or "out of tolerance" isn’t enough — the measurement has to be tied to the exact video frame it happened on, or it can’t be trusted.
Image and measurement data are captured on the same camera clock, so a workpiece’s position, speed or acceleration lines up with the video frame it belongs to.
See it demonstratedThe evidence behind this page
- Continuous recording
- Around the clock, steel mill
- Synchronized demo
- 1,000 fps, 2 cameras + 4 ADC
- Printing deployment
- None yet
Steel-mill installation and the Messe Vision trade-show demonstration.
See the full applicationWhat helps us scope a request in this industry
- Web speed and width
- What has to be traced: registration, tears, coating or splices
- How a recording should map to a position on the roll
- Which line signals should be recorded alongside the video
Recognize this problem in your own process? HSCAM is looking for pilot projects in this industry.
Talk to an engineer about printing & converting
Tell us your process, your speed, and what you need to see or measure.
Helpful, but not required
- What your process does and what goes wrong, or what you cannot see today
- Speed or cycle time, if you know it
- Measurement or trigger signals that exist on the machine
- Environment: temperature, lighting, mounting space
contact@hscam.com · hscam.com
